14' Adirondack Guide Canoe

Write a Review
SKU:
SEL-14ADERONDACKGUIDECANOE
Availability:
Printed plans shipped from and PDF plans emailed from Selway Fisher
$74.00

Description

I am often asked to modify one of my stock designs to suit individual requirements and that is how the 14' Adirondack came about - this design is a development of the 12' x 39" Adirondack canoe (see earlier on this page) and is a roomy guide boat capable of being rowed as well as paddled.

She could also take a rig, leeboards and rudder quite well too and the seat layout can be altered to suit. Standard construction used stitch and tape but mould shapes are also given for those who want to use the clinker/ply method of construction.

14' Adirondack Particulars

LOA 14' 4.27m
Beam 39" 0.99m
Hull Mid Depth 11 7/8" 0.30m
Approx. Dry Weight 48lbs 22kg
Approx. Capacity 650lbs 295kg

Hull Shape

Multi-chine with 5 planks per side plus a very narrow flat bottom panel
Construction Method Stitch & Tape and clinker ply.
Plywood Requirements 4 -5 sheets of 4, 5 or 6mm
Guidance Use General purpose - 2 adults plus gear
Drawing/Design Package 4 x A1 drawings  + 5 x A4 instruction sheets
