12' 3" Plover Double Ended Swampscott/Surf Dory
- SKU:
- SEL-12-3PLOVERDESWAMPSCOTT
- Availability:
- Printed plans shipped and PDF plans emailed from Selway Fisher
Description
| This design is based on a double ended version of our 12' 4" Petite Brise Swampscott dinghy.
Swampscotts as a breed usually have a narrow 'tombstone' transom making them more or less double ended (semi Swampscott dorys have a wider transom) - when they end up with a true 'sharp' aft end, they become 'surf' dorys She can be constructed in stitch and tape or, using the building jog details given, in clinker/ply. The Plover can be built as a pure rowing boat or with the rig - details for a daggerboard are shown but there is also room for a centreboard. She is a jaunty and attractive little boat that can take 2 or 3 sailing and 3 or 4 rowing. |
||
|
Below are photos of the first Plover by Leo Jefferies - this is a clinker/ply version. |
||
 |
 |
|
 |
 |
|
| Below is an example by Adrian Bilek | ||
 |
 |
|
|
12' 3" Plover Double Ended Swampscott/Surf Particulars |
||
| LOA | 12'3" | 3.74m |
| Beam | 4'6" | 1.38m |
| Hull Mid Depth | 1'6" | 0.46m |
| Draft | 5 3/4"/2' 11 1/2" | 0.145/0.9m |
| Sail Area | 68 sq.ft | 6.33 sq.m |
| Approx. Dry Weight | 115lbs | 52kg |
|
Hull Shape |
Narrow flat bottom plus 4 planks per side | |
| Construction Method | Stitch and tape plywood | |
| Major strip wood requirements for hull | 6 sheets of 6 or 9mm plywood | |
| Guidance Use | 2-4 adults sailing and rowing - may have an outboard to one side mounted on a beam | |
| Drawing/Design Package | 4 x A1 drawings + 48x A4 instruction sheets | |
