Howth Head 22 Plans
- SKU:
- SEL-HOWTHHEAD22
- Availability:
- Printed plans shipped and PDF plans emailed from Selway Fisher
Description
The Howth Head is a plywood version of the steel Lambay Island design. Like the Lambay, she is a 22' motor boat with a large cockpit area and comfortable accommodation with 2 large berths, w.c. compartment and galley with dining space in the cockpit.
Construction is ply hull panels over a framework of plywood bulkheads/frames slotted onto a ply fore and aft girder. the chine seams are either conventional wood stringers or expoy and tape. She may take inboard engines up to 50 hp.
|
Howth Head 22 Particulars |
||
| LOA | 22' | 6.71m |
| Beam | 8'3" | 2.52m |
| Hull Mid Depth | 4'1" | 1.25m |
| Draft | 2'9" | 0.84m |
| Maximum Headroom (wheelhouse) | 6'5" | 1.95m |
| Approx. Dry Weight | 3750 lbs | 1700 kg |
| Engine | Up to 50 hp inboard | |
| Hull Shape | V bottom single chine | |
| Construction Methods | Ply over frame | |
| Major plywood requirements for hull | 36 sheets | |
| Guidance Use | Estuary/coastal | |
| Drawing/Design Package | 8 x A1 drawings + 8 x A4 instruction/spec sheets | |
| Additions and alterations included with the plans | ||
