6' Doracle Plans
- SKU:
- SEL-6DORACLE
- Availability:
- Printed plans shipped and PDF plans emailed from Selway Fisher
Description
Designed for a client who wanted a simple stackable fishing dinghy which he could easily carry himself, the Doracle uses just 2 sheets of 4, 5 or 6mm ply. She may be built in 2 pieces with the forward piece stacked inside the aft section. The 2 halves are simply bolted together through the centre frame. Alternatively, the hull may be built in one piece and made stackable by having a removable rowing thwart. The overall beam is 3'8". The hull panel shapes and details are shown for simple stitch and tape construction.
|
6' Doracle Particulars |
||
| LOA | 6' | 1.83m |
| Beam | 3'8" | 1.12m |
| Hull Mid Depth | 1' 5 1/2" | 0.44m |
| Draft | 5" | 0.13m |
| Approx. Dry Weight | 32lbs | 14.5kg |
| Hull Shape | Flat bottom single chine | |
| Construction Method | Stitch and tape | |
| Major plywood requirements for hull | 2 sheets of 4,5 or 6mm Exterior or marine plywood | |
| Guidance Use | 1 adult | |
| Drawing/Design Package | 1 x A1 drawing + 5 x A4 instruction sheets | |
