Fulmar 26' 3" Plans

SKU:
SEL-FULMAR26.3
Availability:
Printed plans shipped and PDF plans emailed from Selway Fisher
$34.00 - $371.00

Description

At 26'3" length on deck, the Fulmar is a heavy displacement cruising yacht which fits a spacious layout into a relatively short length. Her construction is of multi-chine ply extensively using pre-shaped ply bulkheads and girders. The forward accommodation is open plan with a large dining area which can convert to berths followed by a galley and chart area as the main working spaces in the centre of the boat. The aft cabin has a double berth with plenty of stowage space and an engine can be fitted below the centre cockpit or outboards can be accommodated in a locker just in front of the transom. The position of the cockpit allows tiller or wheel steering and for additional protection there is space for a doghouse. Hull/superstructure details only available.

Fulmar 26'3" Particulars

LOD 26'3" 8.03m
Beam 9'9" 2.97m
Draft 2'7" 0.8m
Sail Area 442 sq.ft 41.16 sq.m
Displacement 4.43 tons 4.5 tonnes
Ballast 1.77 tons 1.8 tonnes
Maximum Headroom 6' 1.8m
Accommodation Double bunk (+ additional berth) in aft cabin with large galley, Wc compartment and chart table amidships plus 2 berths forward
Engine
Hull Shape U shape with 3 planks per side
Construction Methods Ply over frame
Major plywood requirements 9mm x 10 sheets
12mm x 45 sheets
18mm x 3 sheets
Guidance Use Offshore
Drawing/Design Package 6 x A1 drawings (hull and deck details only) + 7 x A4 instruction/spec sheets
Additions and alterations included with the plans
