35' Steel Motor Yacht Plans
- SKU:
- SEL-35STEELMY
- Availability:
- Printed plans shipped and PDF plans emailed from Selway Fisher
Description
Similar to the 55 footer below, we have details for the construction of a 35' steel motor yacht hull. The plans include the steel work drawings for the hull and engine beads and the computer generated hull panel shapes. She has a beam of 11'6" (3.5m) and has a double chine hull capable of speeds up to 25 knots.
|
35' Steel MY Particulars |
||
| LOA | 35' | 10.68m |
| Beam | 11'6" | 3.51m |
| Hull Mid Depth | 6'7" | 2m |
| Draft | 2'2" | 0.65m |
| Engine | Twin 150 hp | |
| Hull Shape | V bottom double chine | |
| Construction Methods | Steel - could be ply over frame | |
| Guidance Use | Offshore | |
| Drawing/Design Package | 8 x A1 drawings + 1 x A4 instruction sheet | |
| Additions and alterations included with the plans | ||
