26' Golden Bay Launch
- SKU:
- SEL-26GOLDENBAY
- Availability:
- Printed plans shipped and PDF plans emailed from Selway Fisher
Description
This 26' version of the Golden Bay has the same fairly high and flaired bow sections designed to throw off spray which flow into aft sections which have tumblehome giving her a generous waterline beam for maximum stability.
These drawings show her with a canvas top and a 34hp diesel engine but she could take a solid cabin similar to that on the 21' version and she may be powered by a steam plant (around 15 IHP) or by electric motor.
Construction is for Cedar strip over computer faired moulds. The interior shows simple open plan seating for 8 people but she may be fitted out with other arrangements.
|
26' Golden Bay Particulars |
||
| LOA | 26'5" | 8.03m |
| Beam | 6'8" | 2.03m |
| Hull Mid Depth | 3'5" | 1.04m |
| Draft | 2'9" | 0.84m |
| Approx. Dry Weight | 3308 lbs | 1500 kg |
| Engine | 15 + IHP steam/34 hp diesel | |
| Hull Shape | Round bilge with tumblehome | |
| Construction Methods | Strip plank | |
| Major strip wood requirements for hull | 3280' of 7/8"x1 1/4" (1000m of 22x33mm) WRC | |
| Guidance Use | 8+ adults | |
| Drawing/Design Package | 8 x A1 drawings + 4 x A4 instruction/spec sheets | |
| Additions and alterations included with the plans | ||
