Heron 15 Pocket Cruiser Plans

Write a Review
Printed plans shipped and PDF plans emailed from Selway Fisher
$34.00 - $203.00


The additional 1'4" hull length over the original 14' version gives a lot of useful additional space - enough for 2 comfortable berths, a small galley area and curtained side space for a Porta Potti type wc.

Unlike the 14 foot which has fixed bilge keels, this version has a centreplate (with an external pivot) which means that the interior is not divided by a case.

Construction is centred around a simple plywood framework consisting of a fore and aft girder (which includes the centreplate case) onto which are slotted the ply frames, bulkheads and transom. The hull panels are then fitted over the frameworks and the chines finished with epoxy. The chines can also be solid wood if required.

A pretty looking and simple little ship with plenty of cruising potential.

15' Heron Pocket Cruiser Particulars

LOA 15' 4" 4.67m
Beam 6' 5" 1.96m
Hull Mid Depth 2' 10" 0.85m
Draft 1'4"/3'4" 0.40/1.00m
Sail Area 119 sq.ft 11.03 sq.m
Approx. Dry Weight 1500 lbs 680 kg
Ballast 300 lbs 135 kg
Maximum Headroom 4'6" 1.38m
Hull Shape V bottom single chine
Construction Methods Stitch and tape
Major plywood requirements for hull 18 x 9mm sheets
2 x 12mm sheets
Guidance Use Inland, estuary and coastal for 2-3 adults
Drawing/Design Package 6 x A1 drawings + 8 x A4 instruction sheets
Additions and alterations included with the plans
