14' Duette Cat Boat Plans

Write a Review
Printed plans shipped and PDF plans emailed from Selway Fisher
$34.00 - $182.00


The Duette 14 is a round bilged strip planked cat boat which can be built either as an open day boat or, with it's removable cabin top, as a pocket cruiser with berth space for 2 people and room for a small galley. The mould shapes have been computer generated so that there is no requirement to loft and the builder can get straight into making the building mould. She has a steel centreplate which is "L" shaped so that the centreboard case is kept below the cabin sole and does not encroach on the living space. This arrangement also allows the centreboard pivot to be kept outside below the hull thus avoiding leaks. The old large single sailed cat boat rig is fine but can get a little unwieldy so in the case of Duette, we have broken this down into a gaff sloop with more easily handled sails. The mast is stepped in a tabernacle for easy raising and lowering.

14' Duette Catboat Particulars

LOD 14'5" 4.4m
Beam 7' 2.1m
Hull Mid Depth 2' 0.6m
Draft 1'3"/3' 0.37/0.92m
Sail Area 166 sq.ft 15.4 sq.m
Approx. Dry Weight 1200 lbs 540 kg
Ballast None usually
Maximum Headroom 4' 1 1/2" 1.26m
Hull Shape Round bilge
Construction Methods Strip plank
Major plywood requirements for hull 2130' of 1/2" x 3/4" (650m of 12 x 18mm) Western Red Cedar or Douglas Fir
Guidance Use Inland, estuary and coastal
Drawing/Design Package 4 x A1 drawings + 6 x A4 instruction sheets
Additions and alterations included with the plans
